I.main feature

1、triple output Main output:

fully isolated and adjustable AC & DC voltage, current output, short circuit, overload and over-range automatic protection；

Auxiliary output：

(1) DC:0～220V Amplifier output, short circuit, overload, over-range automatic protection

(2) AC:0～120V Amplifier output, short circuit, overload, over-range automatic protection；0～8A　Amplifier output, short circuit, overload, over-range automatic protection.

2、Maximum output current:0150A.

3、Equipped with a large LCD screen digital AC and DC voltammeter, which can display AC and DC voltage and current values, stopwatch, potential, contact status.

4、Equipped with a measuring input meter, which can be used as a voltage and ammeter；

5、Internal electric stopwatch, can work with live contacts, potential up to 250V, two-way measurement.

6、The lightest design, small size, light weight and full function.

II. Main performance indicators

1、Rated input power：AC:220V±10%·1000VA·50Hz

2、AC output

3、DC Auxiliary output

4、AC Auxiliary output

5、stopwatch

Range：0.0000～999999S, Resolution：0.1mS ,precision：±5 characters

With contact and potential input, maximum input voltage: DC 250V

6、Ammeter

Range：Internal：0.000～150.0A（AC or DC）

External：0.000～6.000A（AC or DC）

precision：0.5%

Measurement method：AC：True RMS    DC：Average value

7、Voltmeter

Range：0.0～600.0V（AC or DC）   precision：0.5%

Measurement method：AC：True RMS  DC：Average value

8、Resistors and capacitors

Resistance：0.5Ω～2.5kΩ,   Capacitor：10uF，maximum voltage AC 450V

9、Split/close auxiliary contacts

Maximum current：1A,  Maximum voltage：AC250V or DC120V

10、Use environment: temperature-10～40℃,relative humidity less than 80%

11、Volume:360 mm×270 mm×250 mm

12、Weight: 18kg
